The Speed Barrier and the Lift Equation
When using the latest hydrofoils, it is possible to ride at speeds far exceeding the wind—up to four times the wind speed downwind and about three times upwind. The mechanism of an underwater foil is based on the exact same fluid dynamics as an airplane wing. The relationship between speed and lift is governed by the following “lift equation”.
L = 1/2 ρv2ACL
- L (Lift): The upward force balancing the rider’s weight
- ρ (Fluid Density): The density of water
- v2 (Velocity squared): The most critical factor
- A (Wing Area): The area of the foil
- CL (Lift Coefficient): A coefficient that changes depending on the wing shape and angle of attack
The most important element here is the “velocity squared (v2)”. As speed increases, the generated lift grows exponentially. This means that the faster you go, the more you face the barrier of how to suppress this massive upward force trying to launch you out of the water and convert it into forward thrust.
The Best “Riding Angle” for Speed and Apparent Wind
To extract pure top speed, what angle should you ride relative to the wind? The fastest angle is not sailing straight downwind (dead downwind). The correct answer is around a “broad reach” (approximately 120 to 150 degrees off the wind), heading diagonally downwind.
By sailing diagonally downwind at high speed, a intense “apparent wind” blows in from the front, which can be converted into thrust. In actual racing, riders create incredible acceleration by heading up slightly to build speed, and the moment they catch a gust, they bear away hard downwind.
Foil Mast Angles and Stabilizer Dynamics
Controlling the angle of the equipment is extremely important for pushing speed to the limit.
Windward Heel
Top riders do not keep their masts perpendicular to the water surface; instead, they ride with the mast heavily leaned (heeled) to windward. When the mast is tilted to windward, the “straight up” lift generated by the front wing redirects diagonally upwind. This “upwind component of lift” directly balances the force of the kite pulling downwind, neutralizing leeway even more powerfully than a daggerboard and generating overwhelming straight-line tracking.
Rake Angle and Downforce
Because lift becomes excessive at high speeds, racers finely adjust the mast’s rake angle to reduce the front wing’s angle of attack. Furthermore, by applying a negative angle of attack to the rear wing (stabilizer), they generate “downforce (downward lift)”. Just like an airplane, the foil balances its pitch by having the front wing lift while the rear wing pulls down. Since the front lift becomes massive at high speeds, optimizing the downforce through rear shim adjustments is essential.
The Physical Truth of “Fat is Fast”
In the racing world, it is often said that “fat is fast”. As the lift equation shows, the front wing generates massive lift at high speeds. While a light rider would be blown out of the water unable to withstand this lift, a heavier rider can use their own weight as a powerful “counterweight (righting moment)” against the kite’s massive pull.
The heavier the rider, the more they can deploy a larger sized kite (engine) even in strong winds and transfer that power to the foil without loss, thereby increasing top speed. Speed without control is meaningless, and physical weight becomes a powerful weapon for mastering top speed.
